This Atari Punk Console kit is based on the original Stepped Tone Generator by Forest M. Mimms III. It creates great lo-fi sounds resembling those from the old style Atari games using an astable square wave oscillator. The main features of the kit are a 9v battery connector snap, an on/off power switch, a 3.5mm jack so that it can be hooked up to other devices such as an amp, speaker or headphones, and two knobs to control the pitch and depth of the quirky raspy tones produced. To find out more please read the full description below.
This kit is rated as easy, takes around 20-45 mins to make and is suitable for all ages. The only equipment needed to complete this kit is a soldering iron and a pair of flush cutters. A really good lead free solder is included with the kit!
Grab yourself a 9v pp3 battery (not included) and connect it up to the battery snap. Turn the APC on using the on/off power switch, and adjust the two knobs to control the pitch and depth of the quirky raspy tones produced.
We are unable to provide individual customer support with kit building so please see the detailed assembly guide here to gauge difficulty before purchasing. Once started, kits cannot be refunded. We also have a handy soldering tutorial here!
A set of connectors is included with your kit to bring the Baby8 and APC together for all sorts of fun which you can see in the video demo further down the page. The set consists of two strips of pin headers and 5 multi-coloured jumper cables for connecting power sharing, 2x CVs, Gate and Ground.
Plug your own headphones into the 3.5mm stereo socket. .
Plug into your own speaker/amp into the 3.5mm stereo socket.
Use the little 25mm speaker included with your kit by soldering it into place.
PCB
500K Ohm Linear Potentiometer (x2)
NE556 Dual 555 Timer IC
100K Resistor
15K Resistor
10K Resistor
1K Resistor (x2)
Connector set
4.7K Ohm Resistor
10uF Electrolytic Capacitor
9V (pp3) Battery Snap
10nF Ceramic Capacitor
100nF Ceramic Capacitor
On/Off Sliding Switch
2-3g Lead Free Solder
small speaker
3.5mm Stereo Jack
